| Chassis type |
Track |
| Track width |
450 mm |
| Travel speed |
3,6 km/h |
| Engine |
100 hp |
| Max. pulling force |
18,3 t |
| Max. drilling length |
400 m |
| Max. expansion diameter |
720 mm |
| Drill rod magazine capacity |
45 pcs |
| Pipeline diameter |
50…500 mm |
| Approximate drilling depth |
500-1500 m |
| Pull-up and pull-down capacity |
60-200 kN |
| Torque |
2500-3700 Nm |
| Pump capacity |
320-420 l/min |
| Discharge pressure |
From 12,5 to 20, MPa |
| Electric motor power |
From 75 to 132 |
| Approximate drilling depth |
570-1240, at D=70 mm |
| Pushing force |
65-140 Kn |
| Execution |
Mine normal / explosion-proof |
| Base execution |
Modular/tracked/track-mounted |
| Maximum rate of rotation |
1500-1350 rpm |
| Maximum torque |
900-3240 Nm |
| Puling force |
200-800 kN |
| Pushing force |
110-150 200-250 kN |
| Torque of rotation |
16500- 40000 Nm |
| Mast options |
— Single — Single with folding parts — Telescopic |
| Maximum productivity of drilling pump / pressure |
1134/10- 2240/20 (l / min) / bar |
